500L-30000L Underground Diesel Fuel Oil Storage Tank 1.6MPa

Name: 500L30000L Underground Diesel Fuel Oil Storage Tank 16MPa
Brand: GNEE
Price: 1 USD

China 500L-30000L Underground Diesel Fuel Oil Storage Tank 1.6MPa wholesale

Brand Name : GNEE

Certification : SGS

Place of Origin : CHINA

MOQ : ≥1sets

Price : depend on product

Payment Terms : MoneyGram,Western Union,T/T,D/P,D/A,L/C

Packaging Details : Wooden box packaging / Outer shell packaging

Loading Medium : -196 - 0 ℃

Operating Pressure : 1.6MPa

Color : white or based on customer's requirement

Height : 2591mm

Inner Vessel Material : 304 Stainless Steel

Placement Method : Horizontal

Package : Sea or land transportation

Key Selling Points : High Productivity

Item : cryogenic pressure tank (LO2,LN2,LAr)

Test Pressure : 0.8MPa-1.6MPa

Inner Vessel Type : Double-walled

Inner Cylinder Material : S30408

Contact Now

High-Quality 500L-30000L Underground Diesel Fuel Oil Storage Tank

Product Description

Underground Storage Tank GNEE's underground steel tanks provide superior structural strength and product compatibility. Designed to withstand the rigors of the underground environment.

We can supplier single-layer, dual-layer and three-layer stainless steel tanks with or without agitation to blend product, with a
wide capacity range from 1000L to 30000L and even larger.

Single-layer tanks are widely applied in the beverage, food, dairy, pharmaceutical, chemical and process industries used as blender tank, buffer tank and storage tank, which cleanable to sanitary standards (e.g. FDA, USDA standards).

Product Parameters

LOX,LIN,LAr Fuel Oil Storage Tank
Water capacity	Working pressure(MPA)	Extemal dimension(mm)	Net weight(kg)	Full-load weight(kg)
Water capacity	Working pressure(MPA)	Extemal dimension(mm)	Net weight(kg)	LOX	LIN	LAr
5m3	1	2216*4405	4130	9830	8180	11130
5m3	1.75	2216*4405	4400	10100	8450	11400
10m3	1	2216*7098	6250	17920	14620	20520
10m3	1.75	2216*7098	6861	18261	14961	20861
15m3	0.8	2616*6520	7380	24480	22530	28380
15m3	1.75	2616*6520	8501	25601	20651	29501
20m3	0.8	2616*8030	8925	31725	25125	36925
20m3	1.75	2616*8030	10378	33178	26578	38378
30m3	0.8	2616*11070	12166	46366	36466	54166
30m3	1.75	2616*11070	14300	48500	38600	56300
50m3	0.8	3020*12685	19494	76494	59994	89494
50m3	1.75	3020*12685	23050	80050	63550	93050
100m3	0.8	3520*17585	33800	147800	114800	174800
100m3	1.6	3520*17585	40550	154550	121550	181550

Configuration:

Manhole

CIP cleaner

Adjustable triangle bracket

Ladder

Thermometer

Liquid lever meter and controller

Eddy-proof board

Dismountable Inlet assembly

Sanitary breathing cover

Unsure whether the specific specifications of the storage tank match your production needs? Contact us—our professional team will recommend suitable specifications and provide reference cases based on your working conditions (e.g., site, medium, production capacity).
